Easy Clean Coatings for Glass and Glazing

Sandblasted Glass Coating (SG 70) is an invisible glass coating that has been specially developed for use on sandblasted or etched glass. The smart coating gives glass a permanent anti-fingerprint finish that prevents glass aesthetics from being compromised either during installation or during its lifetime. The superhydrophobic coating of the textured glass structure ensures that grease and dirt become invisible. Grease and dirt can be easily removed after curing with conventional solvent-based glass cleaners.
For the glass processor or equipment manufacturer,  Sandblasted Glass Coating (SG 70) provides a quick and easy-to-apply solution to protect sandblasted glass against limescale, soap scum and other dirt build up.

Anti-Mist Glass Coating enhances glass and plastic surfaces with anti-mist performance. The intelligent coating provides an anti-fingerprint finish and prevents condensation by creating an ultra-hydrophilic film that causes even the minutest droplets in water vapour to be dispersed across the surface, thereby preventing misting.

For the best results, the anti-mist spray should be applied weekly or monthly, as cleaning or large volumes of water will reduce performance due to lack of chemical bond with the surface.

Applications are ideal for bathroom glass and mirrors, automotive glass, caravan windows and domestic glass (including eyewear).

Clear View Ultra-Hydrophobic Coating, in its diluted form, creates an ultra-hydrophobic  film that repels water, limescale, soap scum and other dirt from non-absorbent surfaces. Nanoflex® Clear View is easy to apply and does not require buffing. This significantly reduces application cost, time and labour (which generally combine to represent 70% of the total cost of application).

Clear View Ultra-Hydrophobic Coating concentrate is available in bulk to the car cleaning and servicing market where it is ideal for the following uses: cleaning dirty surfaces; limescale removal; use as a detergent in windscreen washes; use as a finish in car wash facilities. The superhydrophobic coating provides an anti-fingerprint finish that is ideal for glass, plastic and polished porcelain surfaces.

Optiperl Fluorine Free DWR gives glass and glazed ceramics a unique silde/glide characteristic that means that everyday environmental dirt, dust and water marks are easily removed from the surface with simple blading or use of mild surface cleaners.

The ultra ‘smooth’ surface delivers a high level of hydrophobic and non-stick functionality meaning that environmental debris such as bird faeces, insects and dust can be removed from surfaces easily and without blemish.  This is particularly beneficial for solar panels, as it removes the need for abrasive cloths or cleaners that can leave fine scratch marks on solar cells.

Optiperl Fluorine Free DWR is:

• Invisible to the human eye (coating thickness of approx’ 150nm) totally translucent and doesn’t change optical values or change surface colour.
• UV stable, abrasion resistant
• Resistant to temperature change
• Breathable
• Simple one part application process.
• Chemically resistant between pH2 and pH 13

Optiperl Fluorine Free DWR can be used on:-

• Glass surfaces in sanitary areas (showers and mirrors)
• Glazed ceramic surfaces (toilets, sinks, glazed tiles)

Solar (PV) PanelGuard is an anti-reflective, anti-pollution, anti-soil surface coating for solar panels which increases the light transmission performance of solar panel glass, whilst reducing the amount of dirt and pollution build-up. It’s a water based liquid coating with a silica-based composition that permanently bonds to the surface of solar glass.  It measurably increases the light transmission of the glass  panel by 2.5%, whilst also increasing energy yield overall by 6-7%* by repelling environmental pollution – which can itself reduce overall panel effectiveness by between 15-40%.

Applications

• All types of solar panel glass

Product specification

The coating is UV stable, chemically inert and extremely durable, with hydrophilic dirt repellent properties.  Solar (PV) PanelGuard increases light transmission and efficiency of panels by 2.5% by reducing the amount of light lost through reflection (which can be up to 4% of the light hitting the panel at right-angles). It does not peel or flake and is unaffected by weather extremes.

Solar (PV) PanelGuard offers protection against:

• Environmental pollution from windblown dirt, dust, and traffic pollution
• Damage caused by uric acid in bird droppings – easy clean performance ensures bird droppings simply wash off, or can be removed without the need for abrasive cloths or cleaners which can damage solar cells.
• UV damage – stable for 5-10 years.

Structure

Solar (PV) PanelGuard has a hydrophilic performance which is achieved through surface modification of the silica-based molecules – its main active ingredient. Hydrophilic surfaces make water precipitation spread over the surface as a sheet of liquid, thus removing contamination. In dry conditions dust, dirt and sand particles are prevented from adhering to hydrophilic surfaces thus making Solar (PV) PanelGuard suitable for use in different climates.

Benefits

Light reflection is reduced leading to increases in transmittances by up to 2.5%

Environmental pollution is unable to adhere to the glass – preventing reduction in light absorption and improving the energy yield by 6-7%*.

Weekly or monthly cleaning schedules can be extended because the surface repellence is increased – reducing the need to physically remove dirt particles.

Treatment/Application Methods

Application rate of 5-10ml/m²

Factory application

Solar (PV) PanelGuard solution can be applied during the manufacturing process of solar panels. Curing at temperatures up to 250^oC can reduce drying times and improve mechanical properties.  Solar (PV) PanelGuard has a ‘quick-dry’ function to ensure it is ‘dry to touch’, but it should be kept dry for 24hrs for full bonding to take place ensuring rain fastness.  Full curing occurs at 20^oC for 24hrs.

On-site application

Solar (PV) PanelGuard can be applied pre-or-post installation on site and retrospectively to existing panels that have been in situ for a period. Panels should be clean and thoroughly dry before application which is carried out by either wiping, rolling, spraying, or blading the coating onto the panel surface.

On-site curing times will vary as they are dependent on the environmental conditions at the time, but for full rain resistant bonding keep dry for 24hrs.

*See case study here
